Scan API(LLM x2) Performance Test - VU 500

이코에코(Eco²)/Performance 2026. 1. 27. 13:19

Date: 2026-01-27 04:00 KST
Test Type: k6 Scan Polling Test
Target VUs: 500
Grafana Snapshot: Dashboard Link

Grafana

snapshots.raintank.io

Executive Summary

지표	값	평가
성공률	100%	PASS
E2E P95	83.3s	WARN

1. Test Configuration

test_info:
  target_vus: 500
  test_script: k6-scan-polling-test.js
  endpoint: https://api.dev.growbin.app/api/v1/scan
  timestamp: 2026-01-27T04:00:09.595Z

Test Timeline

Phase	Time (UTC)	Time (KST)	Duration
Ramp-up Start	03:57:10	12:57:10	-
Steady State	03:57:40	12:57:40	2m
Ramp-down Start	03:59:40	12:59:40	-
Test End	04:01:13	13:01:13	-
Total Duration	-	-	~4m

Grafana Dashboard

Snapshot URL: View Dashboard

주요 패널:

Scan API Request Rate
Worker CPU/Memory Usage
RabbitMQ Queue Depth
E2E Latency Distribution
KEDA Scaling Events

2. Test Results

2.1 Throughput & Success Rate

Metric	Value
Total Submitted	1,336
Total Completed	1,336
Total Failed	0
Success Rate	100.0%
Reward Rate	0.0%
Throughput	367.9 req/m

2.2 Latency Distribution

Metric	Value	Target	Status
Scan Submit P95	232ms	< 500ms	PASS
Poll P95	349ms	< 500ms	PASS
E2E P95	83.3s	< 30s	FAIL
E2E Average	59.2s	< 20s	FAIL

2.3 Polling Statistics

Metric	Value
Total Poll Requests	38,860
Avg Polls per Task	29.1
Poll Interval	~2s (estimated)

3. Infrastructure Metrics

3.1 Cluster Overview

Test Time Snapshot (04:00 KST)

Scan Namespace Pods

Pod	Status	Restarts	Node	CPU	Memory
scan-worker-78f8ccdc9-wtxmw	Running	1	k8s-worker-ai	25m	287Mi
scan-worker-canary-ccd48f886-9df4l	Running	1	k8s-worker-ai	24m	310Mi
scan-api-589c5d4c69-g857f	Running	0	k8s-api-scan	6m	149Mi
scan-api-canary-76b4c99cb8-hk9fv	Running	0	k8s-api-scan	5m	113Mi
celery-beat-75c84f45fd-5sdxp	Running	0	k8s-worker-ai-2	4m	133Mi

Worker Node Resource (k8s-worker-ai)

Resource	Usage	Allocation
CPU	389m (19%)	1305m requests / 8750m limits (437% overcommit)
Memory	2.6Gi (69%)	1976Mi requests / 7296Mi limits

3.2 Scan Worker Configuration

deployment:
  replicas: 1 (+ 1 canary)

container:
  image: mng990/eco2:scan-worker-dev-latest
  resources:
    requests:
      cpu: 250m
      memory: 512Mi
    limits:
      cpu: 1
      memory: 1Gi

celery:
  pool: gevent
  concurrency: 100
  prefetch_multiplier: 1
  queues:
    - scan.vision
    - scan.rule
    - scan.answer
    - scan.reward

3.3 KEDA ScaledObject & HPA

ScaledObject Configuration

scan-worker-scaledobject:
  scaleTargetRef: Deployment/scan-worker
  minReplicaCount: 1
  maxReplicaCount: 3
  pollingInterval: 30s
  cooldownPeriod: 300s
  fallback:
    failureThreshold: 3
    replicas: 2

  triggers:
    - type: rabbitmq
      queueName: scan.vision
      value: "10"  # Scale when queue > 10
    - type: rabbitmq
      queueName: scan.answer
      value: "10"
    - type: rabbitmq
      queueName: scan.rule
      value: "20"

  behavior:
    scaleUp:
      stabilizationWindow: 0s
      policies:
        - type: Pods, value: 2, period: 30s
    scaleDown:
      stabilizationWindow: 300s
      policies:
        - type: Percent, value: 50, period: 60s

KEDA Health Status (Post-Test)

Metric	Status	Failures
s0-rabbitmq-scan-vision	Happy	0
s1-rabbitmq-scan-answer	Happy	0
s2-rabbitmq-scan-rule	Happy	0

Scale Events During Test

Time	Event	Reason
04:00:10 UTC	Last Active	Triggers became active
~03:59 UTC	Scale to 3	`scan.vision` queue above target (10)

HPA Event Log:

SuccessfulRescale: New size: 3; reason: external metric
s0-rabbitmq-scan-vision above target

3.4 RabbitMQ Status

Metric	Value
Pod	eco2-rabbitmq-server-0
CPU	45m
Memory	554Mi
Queue Status	Empty (post-test)

3.5 Redis Cluster Status

Redis Pods (Post-Test)

Pod	Purpose	CPU	Memory	Node
rfr-streams-redis-0	Event Streams	10m	123Mi	k8s-redis-streams
rfr-pubsub-redis-0	Pub/Sub (Leader)	7m	70Mi	k8s-redis-pubsub
rfr-pubsub-redis-1	Pub/Sub (Replica)	8m	72Mi	k8s-redis-pubsub
rfr-pubsub-redis-2	Pub/Sub (Replica)	9m	67Mi	k8s-redis-pubsub
rfr-cache-redis-0	Cache	8m	218Mi	k8s-redis-cache
rfr-auth-redis-0	Auth Sessions	7m	66Mi	k8s-redis-auth

Redis Sentinel Pods

Pod	CPU	Memory
rfs-streams-redis	8m	55Mi
rfs-pubsub-redis (x3)	7-8m	51-52Mi
rfs-cache-redis	8m	69Mi
rfs-auth-redis	8m	51Mi

Observation: Redis 클러스터는 테스트 중 안정적으로 유지됨. Cache Redis 메모리 사용량(218Mi)이 다른 인스턴스 대비 높음.

3.6 All Cluster Nodes Resource

Node	CPU	CPU%	Memory	Mem%	Role
k8s-worker-ai	389m	19%	2.6Gi	69%	AI Workers
k8s-worker-ai-2	76m	3%	2.1Gi	56%	Celery Beat
k8s-api-scan	69m	3%	2.4Gi	65%	Scan API
k8s-rabbitmq	119m	5%	2.0Gi	55%	Message Queue
k8s-redis-streams	108m	5%	1.2Gi	66%	Redis Streams
k8s-redis-pubsub	172m	8%	1.5Gi	86%	Redis Pub/Sub
k8s-logging	250m	12%	7.2Gi	94%	ELK Stack

Warning: k8s-logging 노드 메모리 94% 사용 중 - ELK 스택 리소스 점검 필요

4. Prometheus Metrics (Test Window: 03:57:10 ~ 04:01:13 UTC)

4.1 Scan Worker CPU Usage

Pod	Start	Peak	End	Trend
scan-worker-78f8ccdc9-wtxmw	1.53	1.72	0.23	↗↘
scan-worker-78f8ccdc9-jhrgg	-	1.83	0.34	↗↘ (scale-up)
scan-worker-78f8ccdc9-sqcbr	-	1.84	0.36	↗↘ (scale-up)
scan-worker-canary	1.46	1.74	0.35	↗↘

Query:

sum(rate(container_cpu_usage_seconds_total{namespace="scan",pod=~"scan-worker.*"}[1m])) by (pod)

4.2 Scan Worker Memory Usage

Pod	Start	Peak	End
scan-worker-wtxmw	750MB	1.30GB	1.17GB
scan-worker-jhrgg	337MB	1.18GB	1.12GB
scan-worker-sqcbr	481MB	1.24GB	1.14GB
scan-worker-canary	1.42GB	1.62GB	1.55GB

Query:

sum(container_memory_working_set_bytes{namespace="scan",pod=~"scan-worker.*"}) by (pod)

4.3 HPA Replica Count

Time (UTC)	scan-worker	scan-api
03:57:10	3	1
03:57:40	3	2
03:58:10	3	3
04:01:13	3	3

Query:

kube_horizontalpodautoscaler_status_current_replicas{horizontalpodautoscaler=~".*scan.*"}

Observation: scan-worker는 테스트 시작 전 이미 3 replicas로 스케일업됨 (이전 요청 영향)

4.4 RabbitMQ Queue Depth

Queue	Start	Peak	Peak Time
scan.vision	352	352	03:57:10
scan.answer	14	258	03:58:10
scan.rule	73	268	03:57:40
scan.reward	2	155	03:58:40

Query:

rabbitmq_queue_messages{queue=~"scan.*"}

Observation: 테스트 종료 시 모든 큐가 0으로 drain됨 (정상 처리 완료)

4.5 RabbitMQ Consumer Count

Queue	Min	Max	Steady
scan.vision	2	4	4
scan.answer	2	4	4
scan.rule	2	4	4
scan.reward	2	4	4

Query:

rabbitmq_queue_consumers{queue=~"scan.*"}

4.6 Scan API CPU Usage

Pod	Start	Peak	End	Note
scan-api-g857f	0.47	1.30	0.01	Original
scan-api-vqwzw	-	0.74	0.01	Scale-up +1
scan-api-pzppj	-	0.63	0.01	Scale-up +2
scan-api-canary	0.01	0.01	0.01	Idle

Query:

sum(rate(container_cpu_usage_seconds_total{namespace="scan",pod=~"scan-api.*"}[1m])) by (pod)

4.7 Redis Memory Usage

Instance	Start	Peak	End	Delta
rfr-streams	42.7MB	51.6MB	51.6MB	+8.9MB
rfr-cache	26.0MB	102MB	102MB	+76MB
rfr-pubsub-0	2.1MB	2.2MB	2.1MB	-
rfr-auth	1.0MB	1.0MB	1.0MB	-

Query:

redis_memory_used_bytes{namespace="redis"}

Observation: rfr-cache 메모리가 테스트 중 4배 증가 (LLM 응답 캐싱)

4.8 All Workers Status

Namespace	Worker	Replicas	Node	Status
scan	scan-worker	1	k8s-worker-ai	Running
scan	scan-worker-canary	1	k8s-worker-ai	Running
chat	chat-worker	1	k8s-worker-ai	Running
character	character-match-worker	2	k8s-worker-storage, storage-2	Running
character	character-worker	1 (+1 canary)	k8s-worker-storage-2, storage	Running
auth	auth-worker	1 (+1 canary)	k8s-worker-storage-2, storage	Running
users	users-worker	1 (+1 canary)	k8s-worker-storage, storage-2	Running
info	info-worker	1	k8s-api-info	Running

Total Workers: 13 pods across 4 nodes

4.8 Event Router Configuration

redis:
  streams_url: redis://rfr-streams-redis.redis.svc.cluster.local:6379/0
  pubsub_url: redis://pubsub-redis-master.redis.svc.cluster.local:6379/0

5. Worker Log Analysis

5.1 Task Processing Times (Sample from Logs)

Task Type	Min	Max	Avg	Note
scan.vision	4.46s	6.21s	4.5s	OpenAI Vision API
scan.rule	0.04s	0.18s	0.04s	Local lookup (Redis)
scan.answer	4.85s	8.92s	6.7s	OpenAI Chat Completion
scan.reward	0.03s	0.05s	0.05s	Character match + event

Detailed Sample (03:59:38 - 03:59:52 KST)

03:59:38.311  scan.answer   4.847s  task=fb2e58f9
03:59:38.469  scan.reward   0.035s  task=bf38ff01
03:59:39.002  scan.rule     0.038s  task=deeb6139
03:59:39.071  scan.reward   0.045s  task=9a113200
03:59:39.570  scan.answer   6.685s  task=b2c6ed05
03:59:39.901  scan.reward   0.048s  task=66f5daa8
03:59:40.017  scan.vision   4.564s  task=c5956559  (duration_vision_ms: 4466)
03:59:41.025  scan.reward   0.038s  task=8b47d5bf
03:59:41.061  scan.answer   7.637s  task=3037e333
03:59:42.502  scan.rule     0.042s  task=236ccd0b  (duration_rule_ms: 0.175)
03:59:44.630  scan.answer   6.899s  task=d6f35d05
03:59:45.010  scan.answer   8.916s  task=d64ee5b2
03:59:47.353  scan.answer   5.809s  task=fd18b15e
03:59:52.583  scan.reward   0.055s  task=4c96d003

Task Statistics (from logs):

Tasks processed in last hour: 574 succeeded
Tasks processed in last 2 hours: 1,148 total (vision + rule + answer + reward)
Estimated tasks during test window (4m): ~300 complete scan flows

5.2 Task Flow

scan.vision (4.5s avg)
    ↓
scan.rule (0.04s)
    ↓
scan.answer (6.7s avg)
    ↓
scan.reward (0.05s)
────────────────────
Total: ~11-12s per task (sequential)

5.3 Observations from Logs

LLM API Calls: 모든 OpenAI API 호출 성공 (HTTP 200)
Reward Processing: reward_character_event_dispatched 정상 발생
Character Match: Character match completed 로그 확인
Worker Sync: 간헐적 heartbeat miss 발생 (users-worker-canary)

6. Bottleneck Analysis

6.1 E2E Latency Breakdown

┌─────────────────────────────────────────────────────────────┐
│                    E2E Latency: 59.2s (avg)                  │
├─────────────────────────────────────────────────────────────┤
│                                                              │
│  [Queue Wait]     [Vision]    [Rule]  [Answer]   [Reward]   │
│  ~~~~~~~~~~~~     ~~~~~~~~    ~~~~~~  ~~~~~~~~   ~~~~~~~~   │
│     ~47s           4.5s       0.04s    6.7s       0.05s     │
│     (80%)          (8%)       (0%)     (11%)      (0%)      │
│                                                              │
└─────────────────────────────────────────────────────────────┘

Primary Bottleneck: Queue Wait Time (~47s)

Worker concurrency: 100 (gevent)
2 workers total (stable + canary)
Max concurrent tasks: 200
VU 500 with burst → Queue backlog

6.2 Why Queue Wait is High

HPA Scale-up Delay: 부하 감지 후 스케일업까지 지연
OpenAI Rate Limits: Vision API 동시 요청 제한 가능성
gevent Greenlet Scheduling: I/O 대기 중 context switch 오버헤드

7. Comparison with Previous Tests

7.1 Today's Tests (2026-01-27)

Metric	UTC 04:00)	Change
Submitted	1,336	+426%
Completed	1,336	-
Failed	0	-100%
Success Rate	100%	FIXED
E2E P95	83.3s	N/A*

7.2 vs Blog VU 500 Test (Reference: Scan API 부하 테스트 (300-500VU))

Metric	VU 500 (25.12.29)	VU 500 (Latest)	Delta	비고
요청 수	1,990	1,336	-33%	테스트 시간 차이
완료율	94.0%	100%	+6%	개선
성공률	99.7%	100%	+0.3%	-
E2E P95	76.4s	83.3s	+9%	악화
E2E Avg	-	59.2s	-	-
Throughput	438 req/m	367.9 req/m	-16%	-
Scan API P95	154ms	232ms	+51%	-

주요 개선점: Pub/Sub - SSE GW Connection 최적화, worker-ai 노드 +1
완료율 개선: 94% → 100% (+6%) - 시스템 안정화
E2E P95 악화: 76.4s → 83.3s (+9%) - 대기열 증가
Throughput 감소: 438 → 367.9 req/m (-16%) - 요청 수 차이

7.3 VU별 추이

VU	요청 수	완료율	E2E P95	Throughput	평가
50	685	99.7%	17.7s	198 req/m	Baseline
200	1,649	99.8%	33.2s	367 req/m	정상
250	1,754	99.9%	40.5s	417.6 req/m	최적점
300	1,732	99.9%	48.5s	402 req/m	포화 시작
400	1,901	98.9%	62.2s	422.2 req/m	한계 근접
500	1,990	94.0%	76.4s	438 req/m	SLA 초과
500(Latest)	1,336	100%	83.3s	367.9 req/m	안정화됨

결론:

안정성: 금일 테스트가 완료율 100%로 더 안정적
성능: E2E 레이턴시는 약간 증가 (+9%)
권장 VU: SLA(E2E < 60s) 기준 250-300 VU 권장

8. Appendix

8.1 Prometheus Query Reference

아래 쿼리들을 사용해 테스트 시간대 메트릭을 수집했습니다.

Metric	PromQL Query
Worker CPU	`sum(rate(container_cpu_usage_seconds_total{namespace="scan",pod=~"scan-worker.*"}[1m])) by (pod)`
Worker Memory	`sum(container_memory_working_set_bytes{namespace="scan",pod=~"scan-worker.*"}) by (pod)`
API CPU	`sum(rate(container_cpu_usage_seconds_total{namespace="scan",pod=~"scan-api.*"}[1m])) by (pod)`
HPA Replicas	`kube_horizontalpodautoscaler_status_current_replicas{horizontalpodautoscaler=~".scan."}`
RabbitMQ Queue Depth	`rabbitmq_queue_messages{queue=~"scan.*"}`
RabbitMQ Consumers	`rabbitmq_queue_consumers{queue=~"scan.*"}`
Redis Memory	`redis_memory_used_bytes{namespace="redis"}`

Time Range Parameters:

start=1769486230  # 2026-01-27T03:57:10Z
end=1769486473    # 2026-01-27T04:01:13Z
step=30s

8.2 Raw Test Output

{
  "test_info": {
    "target_vus": 500,
    "duration_seconds": 1769486191.701171
  },
  "results": {
    "total_submitted": 1336,
    "total_completed": 1336,
    "total_failed": 0,
    "success_rate": "100.0%",
    "reward_rate": "0.0%"
  },
  "latency": {
    "scan_submit_p95": "232ms",
    "poll_p95": "349ms",
    "e2e_p95": "83.3s",
    "e2e_avg": "59.2s"
  },
  "polling": {
    "total_poll_requests": 38860,
    "avg_polls_per_task": "29.1"
  },
  "throughput": {
    "requests_per_minute": "367.9 req/m"
  }
}

8.3 Test Environment

Component	Version/Config
k6	v0.49+
Kubernetes	Self-managed (kubeadm, 24-node)
Istio	1.24.1
RabbitMQ	3.x (Cluster Operator)
Celery	5.x (gevent pool)
OpenAI Model	gpt-5.2
Prometheus	kube-prometheus-stack

8.4 Related Files

Test Script: e2e-tests/performance/k6-scan-polling-test.js
Result JSON: k6-scan-polling-vu500-2026-01-27T04-00-09-595Z.json
HPA Config: k8s/scaling/scan-worker-scaledobject.yaml
Grafana Snapshot: Link

'이코에코(Eco²) > Performance' 카테고리의 다른 글

Scan API(LLM x2) Performance Test - VU 700 (0)	2026.01.27
Scan API(LLM x2) Performance Test - VU 1000 (Tier 4) (0)	2026.01.27
Scan API(LLM x2) Performance Test - VU 1000 (Tier 3) (0)	2026.01.27
Scan API(LLM x2) Performance Test - VU 600 (0)	2026.01.27
Scan API 600 VUs Load Test: 처리량 포화 분석 리포트 (0)	2025.12.29

ABOUT ME

Executive Summary

1. Test Configuration

Test Timeline

Grafana Dashboard

2. Test Results

2.1 Throughput & Success Rate

2.2 Latency Distribution

2.3 Polling Statistics

3. Infrastructure Metrics

3.1 Cluster Overview

Scan Namespace Pods

Worker Node Resource (k8s-worker-ai)

3.2 Scan Worker Configuration

3.3 KEDA ScaledObject & HPA

ScaledObject Configuration

KEDA Health Status (Post-Test)

Scale Events During Test

3.4 RabbitMQ Status

3.5 Redis Cluster Status

Redis Pods (Post-Test)

Redis Sentinel Pods

3.6 All Cluster Nodes Resource

4. Prometheus Metrics (Test Window: 03:57:10 ~ 04:01:13 UTC)

4.1 Scan Worker CPU Usage

4.2 Scan Worker Memory Usage

4.3 HPA Replica Count

4.4 RabbitMQ Queue Depth

4.5 RabbitMQ Consumer Count

4.6 Scan API CPU Usage

4.7 Redis Memory Usage

4.8 All Workers Status

4.8 Event Router Configuration

5. Worker Log Analysis

5.1 Task Processing Times (Sample from Logs)

Detailed Sample (03:59:38 - 03:59:52 KST)

5.2 Task Flow

5.3 Observations from Logs

6. Bottleneck Analysis

6.1 E2E Latency Breakdown

6.2 Why Queue Wait is High

7. Comparison with Previous Tests

7.1 Today's Tests (2026-01-27)

7.2 vs Blog VU 500 Test (Reference: Scan API 부하 테스트 (300-500VU))

7.3 VU별 추이

8. Appendix

8.1 Prometheus Query Reference

8.2 Raw Test Output

8.3 Test Environment

8.4 Related Files

'이코에코(Eco²) > Performance' 카테고리의 다른 글

관련글 관련글 더보기

티스토리툴바
